Hitachi LX110-7 Wheel Loader

Hitachi LX110-7 Wheel Loader Specs front
Hitachi LX110-7 Wheel Loader Specs front
Hitachi LX110-7 Wheel Loader Specs side
Hitachi LX110-7 Wheel Loader Specs side
Hitachi LX110-7 Wheel Loader Specs back
Hitachi LX110-7 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.06 ft in

Dimensions

A

Length with Bucket on Ground

22.15 ft in

B

Width Over Tires

7.91 ft in

C

Height to Top of Cab

10.31 ft in

D

Wheelbase

9.52 ft in

E

Ground Clearance

1.32 ft in

F

Hinge Pin - Max Height

12.19 ft in

H

Reach at Max Lift and Dump

3.52 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2353

Engine Model

BB-6BG1T

Net Power

128 hp

Power Measured @

2200 rpm

Displacement

396.3 cu in

Aspiration

Turbocharger

Operational

Operating Weight

22244.7 lb

Fuel Capacity

45 gal

Hydraulic System Fluid Capacity

21.2 gal

Engine Oil Fluid Capacity

3.5 gal

Cooling System Fluid Capacity

8.2 gal

Transmission Fluid Capacity

5.3 gal

Front Axle/Diff Fluid Capacity

5.6 gal

Rear Axle/Diff Fluid Capacity

5.6 gal

Static Tipping Weight

17416.6 lb

Turning Radius

16.4 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Tire Size

17.5-25-12PR (L3)

Transmission

Transmission Type

Torque converter ; countershaft type powershift with electrically controlled

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

21.5 mph

Max Speed - Reverse

21.8 mph

Hydraulic System

Pump Type

gear type

Relief Valve Setting

2986.4

Pump Flow Capacity

13.8 gal/min

Raise Time

5.9 sec

Dump Time

1.4 sec

Lower Time

3 sec

Bucket

Breakout Force

22031.3 lb

Dump Clearance at Max Raise

9.1 ft in

Bucket Width

8.2 ft in

Bucket Capacity - heaped

2.7 yd3

Bucket Capacity - struck

2.3 yd3

Dimensions

Length with Bucket on Ground

22.2 ft in

Width Over Tires

8 ft in

Height to Top of Cab

10.4 ft in

Ground Clearance

1.4 ft in

Wheelbase

9.6 ft in

Hinge Pin - Max Height

12.2 ft in

Reach at Max Lift and Dump

3.6 ft in
