Volvo L90D Wheel Loader

Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.29 ft in

Dimensions

A

Length with Bucket on Ground

25.14 ft in

B

Width Over Tires

8.17 ft in

C

Height to Top of Cab

10.63 ft in

D

Wheelbase

9.85 ft in

E

Ground Clearance

1.19 ft in

F

Hinge Pin - Max Height

13.03 ft in

H

Reach at Max Lift and Dump

3.65 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2244

Engine Model

TD 63 KBE

Net Power

153 hp

Gross Power

160 hp

Power Measured @

2100 rpm

Displacement

334 cu in

Torque Measured @

1100 rpm

Max Torque

512.7

Aspiration

turbocharged

Operational

Operating Weight

33444.2 lb

Fuel Capacity

55.5 gal

Hydraulic System Fluid Capacity

34.4 gal

Engine Oil Fluid Capacity

4.3 gal

Cooling System Fluid Capacity

14.1 gal

Transmission Fluid Capacity

8.8 gal

Front Axle/Diff Fluid Capacity

9.6 gal

Rear Axle/Diff Fluid Capacity

10.9 gal

Static Tipping Weight

23744 lb

Turning Radius

19.5 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

60 amps

Rear Axle Oscillation

30 degrees

Tire Size

20.5R25*L2

Transmission

Transmission Type

Volvo HT 131, Countershaft-type

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

23.8 mph

Max Speed - Reverse

23.8 mph

Hydraulic System

Pump Type

vane pump

Relief Valve Setting

3263.4

Pump Flow Capacity

53.4 gal/min

Raise Time

5.5 sec

Dump Time

1.9 sec

Lower Time

2.3 sec

Bucket

Breakout Force

24459.3 lb

Dump Clearance at Max Raise

9.3 ft in

Bucket Width

8.7 ft in

Bucket Capacity - heaped

3.6 yd3

Dimensions

Length with Bucket on Ground

25.2 ft in

Width Over Tires

8.2 ft in

Height to Top of Cab

10.7 ft in

Ground Clearance

1.2 ft in

Wheelbase

9.9 ft in

Hinge Pin - Max Height

13.1 ft in

Reach at Max Lift and Dump

3.7 ft in
