John Deere 444K Wheel Loader
Units
Dimensions
Bucket
Breakout - Bucket
7960 (17549) kgf (lbf)
Bucket Capacity - Smallest
2.49yd3
Largest Bucket Capacity
4.06yd3
Dimensions
E
Ground Clearance
15.48in
A
Length With Bucket On Ground
22.51ft in
B
Width Over Tires
7.93ft in
D
Wheelbase
9.06ft in
F
Hinge Pin - Max Height
11.82ft in
H
Reach At Max Lift And Dump
4.73ft in
Turning Circle
38.23ft in
Height Over Cab
10.41ft in
Specifications
Engine
Pump
Piston
Engine Output-Net
123.4hp
Transmission Type
Powershift
Engine Make
John Deere
Engine Model
PowerTech PSS 4045
Torque
374lb ft
Rated Speed
2100rpm
Displacement
274.7cu in
Torque Rise
34%
System Voltage
24V
Emission Level
Tier 4
Alternator
100amps
Driveline
Ride Control System
Optional
Service Brake Type
Wet Multi Disc
Parking Brake Type
Wet Multi Disc
Differential Lock
Front- Locking, Rear- Open
Service Brake Actuation
Hydraulic
Tire Size - Standard
17.5 R25
Service Brake - Location
All Wheels
Capacities
Hydraulic Tank
31.4gal
Heaped Capacity
2.5yd3
Transmission
4.9gal
Operational
Operating Weight
25022.5lb
Fuel Capacity
58.2gal
Front Axle/Diff Fluid Capacity
5.9gal
Rear Axle/Diff Fluid Capacity
5.9gal
Transmission
Pump Flow
37gal/min
System Pressure
248.3psi
