Caterpillar 966G Wheel Loader

Caterpillar 966G Wheel Loader Specs front
Caterpillar 966G Wheel Loader Specs front
Caterpillar 966G Wheel Loader Specs side
Caterpillar 966G Wheel Loader Specs side
Caterpillar 966G Wheel Loader Specs back
Caterpillar 966G Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

10.18 ft in

Dimensions

A

Length with Bucket on Ground

28.96 ft in

B

Width Over Tires

9.72 ft in

C

Height to Top of Cab

11.78 ft in

E

Ground Clearance

1.42 ft in

H

Reach at Max Lift and Dump

4.29 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

3306DITA

Net Power

253 hp

Gross Power

235 hp

Power Measured @

2200 rpm

Displacement

640.8 cu in

Operational

Operating Weight

50155.2 lb

Fuel Capacity

108.4 gal

Hydraulic System Fluid Capacity

54.7 gal

Static Tipping Weight

34731.7 lb

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

23.2 mph

Max Speed - Reverse

26.3 mph

Hydraulic System

Raise Time

6.6 sec

Dump Time

1.3 sec

Lower Time

1.8 sec

Bucket

Breakout Force

44120 lb

Dump Clearance at Max Raise

10.2 ft in

Bucket Width

10.1 ft in

Bucket Capacity - heaped

4.3 yd3

Dimensions

Length with Bucket on Ground

29 ft in

Width Over Tires

9.8 ft in

Height to Top of Cab

11.8 ft in

Ground Clearance

1.5 ft in

Reach at Max Lift and Dump

4.3 ft in
