Caterpillar 950M (TIER 4/STAGE IV) (2016) Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Dimensions - High Lift

E

Ground Clearance

1.17ft in

Wheel Base

11ft in

Centerline Of Rear Axle To Edge Of Counterweight

6.33ft in

Centerline Of Rear Axle To Hitch

5.5ft in

Height - Top Of Exhaust Pipe

11.17ft in

Height - Top Of Hood

8.83ft in

Height - Top Of Rops

11.33ft in

Hinge Pin Height At Carry Height

2.58ft in

Hinge Pin Height At Maximum Lift

14.83ft in

Lift Arm Clearance At Maximum Lift

11.92ft in

Maximum Width - Over Tires - Loaded

9.25ft in

Overall Length - Without Bucket

24.58ft in

Rack Back - Carry Height

49 degrees

Rack Back - Maximum Lift

59 degrees

Rack Back At Ground

40 degrees

Tread Width

7ft in

Note

All dimensions are approximate and based on Michelin 23.5R25 XHA2 L3 radial tires.

Dimensions - Standard Lift

E

Ground Clearance

1.17ft in

Rack Back - Maximum Lift

59 degrees

Centerline Of Rear Axle To Edge Of Counterweight

6.33ft in

Lift Arm Clearance At Maximum Lift

10.75ft in

Centerline Of Rear Axle To Hitch

5.5ft in

Maximum Width - Over Tires - Loaded

9.25ft in

Note

All dimensions are approximate and based on Michelin 23.5R25 XHA2 L3 radial tires.

Tread Width

7ft in

Height - Top Of Exhaust Pipe

11.17ft in

Height - Top Of Hood

8.83ft in

Overall Length - Without Bucket

22.67ft in

Height - Top Of Rops

11.33ft in

Rack Back At Ground

36 degrees

Hinge Pin Height At Carry Height

2.08ft in

Rack Back - Carry Height

49 degrees

Wheel Base

11ft in

Hinge Pin Height At Maximum Lift

13.25ft in


Specifications

Engine

Displacement

428cu in

Net Power - Iso 9249

230hp

Engine Model

Cat C7.1 ACERT

Peak Gross Torque - 1,300 Rpm - Sae J1995

911lb ft

Maximum Gross Power - 2,100 Rpm - Sae J1995

250hp

Maximum Net Power - 2,100 Rpm - Sae J1349

230hp

Peak Gross Torque - 1,300 Rpm - Iso 14396

908lb ft

Maximum Gross Power - 2,100 Rpm - Iso 14396 - Metric

253hp

Maximum Net Power - 2,100 Rpm - Iso 9249 - Metric

232hp

Maximum Gross Power - 2,100 Rpm - Iso 14396

249hp

Maximum Net Power - 2,100 Rpm - Iso 9249

230hp

Maximum Net Torque - 1,300 Rpm

858lb ft

Operational

Operating Weight

42357lb

Transmission

Forward - 1

4.3mph

Forward - 2

7.5mph

Forward - 3

12mph

Forward - 4

16mph

Forward - 5

24.5mph

Note

Maximum travel speed in standard vehicle with empty bucket and standard L3 tires with 787 mm (31 in) roll radius.

Reverse - 1

4.3mph

Reverse - 2

7.5mph

Reverse - 3

16mph

Weights

Operating Weight

42357lb

Note

Weight based on a machine configuration with Michelin 23.5R25 XHA2 L3 radial tires, full fluids, operator, standard counterweight, cold start, roading fenders, Product Link, manual diff lock/open axles (front/rear), power train guard, secondary steering, sound suppression and a 3.1 m3 (4.1 yd3) general purpose bucket with BOCE.

Buckets

Bucket Capacities

2.5-9.2 m? (3.3-12.0 yd?)

Hydraulic System

Hydraulic Cycle Time - Total

8.9 s

Implement System - Maximum Operating Pressure

4250 psi

Implement System - Maximum Pump Output At 2,150 Rpm

76 gal/min

Implement Pump Type

Variable Axial Piston

Operating Specifications

Note (1)

For a machine configuration as defined under ?Weight.?

Note (2)

Full compliance to ISO 143971:2007 Sections 1 thru 6, which requires 2% verification between calculations and testing.

Breakout Force

40690lb

Static Tipping Load - Full 40 Degrees Turn - With Tire Deflection

24262lb

Static Tipping Load - Full 40 Degrees Turn - No Tire Deflection

25926lb

Service Refill Capacities

Cooling System

15.6gal

Fuel Tank

72.6gal

Crankcase

5.8gal

Def Tank

4.2gal

Hydraulic Tank

33gal

Transmission

11.4gal

Differential - Final Drives - Front

11.4gal

Differential - Final Drives - Rear

11.4gal

Sound

Note (1)

*Distance of 15 m (49.2 ft), moving forward in second gear ratio.

Note (2)

**European Union Directive ?2000/14/EC? as amended by ?2005/88/EC.?

With Cooling Fan Speed At Maximum Value - Operator Sound Pressure Level (Iso 6396:2008)

70 dB(A)

With Cooling Fan Speed At Maximum Value - Exterior Sound Power Level (Iso 6395:2008)

108 dB(A)

With Cooling Fan Speed At Maximum Value - Exterior Sound Pressure Level (Sae J88:2013)

75 dB(A)*

With Cooling Fan Speed At 70% Of Maximum Value - Operator Sound Pressure Level (Iso 6396:2008)

69 dB(A)

With Cooling Fan Speed At 70% Of Maximum Value - Exterior Sound Power Level (Iso 6395:2008)

106 LWA**

Bucket Capacities

Bucket Range

2.5-9.2 m? (3.3-12.0 yd?)
