Terex TXL400-2 Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Bucket

G

Dump Clearance At Max Raise

9.77ft in

Bucket Capacity - Heaped

5.11yd3

Bucket Width

10.5ft in

Breakout Force

49458lb

Dimensions

E

Ground Clearance

1.68ft in

A

Length With Bucket On Ground

28.58ft in

B

Width Over Tires

9.8ft in

C

Height To Top Of Cab

11.56ft in

D

Wheelbase

11.49ft in

F

Hinge Pin - Max Height

14.28ft in

H

Reach At Max Lift And Dump

4.5ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2347

Engine Model

QSL 9

Gross Power

280hp

Power Measured @

2000rpm

Max Torque

1072lb ft

Displacement

543cu in

Torque Measured @

1400rpm

Aspiration

turbocharged

Operational

Operating Weight

49604lb

Fuel Capacity

96.5gal

Hydraulic System Fluid Capacity

70.1gal

Engine Oil Fluid Capacity

6.7gal

Cooling System Fluid Capacity

13.3gal

Transmission Fluid Capacity

14.3gal

Front Axle/Diff Fluid Capacity

11.9gal

Rear Axle/Diff Fluid Capacity

11.1gal

Static Tipping Weight

41667.4lb

Turning Radius

20.9ft in

Operating Voltage

24V

Alternator Supplied Amperage

70amps

Rear Axle Oscillation

24degrees

Tire Size

26.5-25-20PR-L3

Transmission

Transmission Type

full power shift

Number Of Forward Gears

4

Number Of Reverse Gears

3

Max Speed - Forward

23.7mph

Max Speed - Reverse

17.4mph

Hydraulic System

Relief Valve Setting

3626psi

Pump Flow Capacity

100.4gal/min

Raise Time

6sec

Dump Time

1.4sec

Lower Time

3sec

Pump Type

two load sensing axial piston pumps
