New Holland B110C Loader Backhoe

New Holland B110C Loader Backhoe Specs front
New Holland B110C Loader Backhoe Specs front
New Holland B110C Loader Backhoe Specs side
New Holland B110C Loader Backhoe Specs side
New Holland B110C Loader Backhoe Specs extended
New Holland B110C Loader Backhoe Specs extended
Units

Dimensions

Dimensions

A

Transport Length

23.07 ft in

B

Transport Width

7.55 ft in

C

Transport Height

12.52 ft in

D

Wheelbase

85.63 in

E

Ground Clearance

15.52 in

Loader

H

Reach at Max Dump Height

2.32 ft in


Specifications

Engine

Engine Model

FPT F5HFL413B*A

Gross Power

110 hp

Net Power

108 hp

Torque Measured @

1400 rpm

Net Max Torque

344 lb ft

Displacement

207 cu in

Capacities

Fuel Tank

34.7 gal

Hydraulic Tank

13.4 gal

Cooling system

6.4 gal

DEF Tank

3.5 gal

Hydraulic system

36.2 gal

Engine Oil

2.2 gal

Backhoe

STANDARD Max dig depth

15.6 ft in

STANDARD Loading Height

12.4 ft in

STANDARD Max pin height

16.4 ft in

STANDARD Loading Reach @ max height

5.3 ft in

STANDARD Reach from swing post,

17.9 ft in

STANDARD Bucket capacity

7408.3 yd3

STANDARD Bucket digging force

12969.8 lb

STANDARD Crowd digging force

8527.5 lb

EXTENDED Max dig depth

19 ft in

EXTENDED Loading Height

14.6 ft in

EXTENDED Max pin height

17.6 ft in

EXTENDED Loading Reach @ max height

7.9 ft in

EXTENDED Reach from swing post

21.1 ft in

EXTENDED Bucket capacity,

21.7 yd3

EXTENDED Bucket digging force

19.4 lb

EXTENDED Crowd digging force

19.8 lb

Transmission

POWER SHUTTLE Gear forward

4

POWER SHUTTLE Gear reverse

4

POWERSHIFT Gear forward

4

POWERSHIFT Gear reverse

3

SHUTTLE Max forward speed

22.5 mph

SHIFT Max Fwd travel speed

22.1 mph

Loader

Height to hinge pin

11.5 ft in

Weights

Base Unit

18523.3 lb

Loader

Bucket Breakout Force

17436 lb

Lift Capacity at Full Height

7833.1 lb

Reach at Max Dump Height

2.4 ft in

Hydraulic System

System relief pressure

3045 psi

Pump Flow Capacity

40 gal/min

Dimensions

Ground Clearance

15.6 in

Stabilizer spread

10.6 ft in

Stabilizer operating

10.6 ft in

Wheelbase

85.7 in

Transport Length

23.1 ft in

Transport Width

7.6 ft in

Transport Height

12.6 ft in

Height to Top of Suspended Cab

9.5 ft in
