Case 590 Super M Series III Loader Backhoe

Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Units

Dimensions

Backhoe

J

Load Height - Std

11.42ft in

K

Reach From Swivel - Std

19.68ft in

L

Dig Depth - Std

15.92ft in

M

Reach at Load Height - Std

9.5ft in

Dimensions

A

Transport Length

23.58ft in

B

Transport Width

7.75ft in

C

Transport Height

11.19ft in

D

Wheelbase

7.04ft in

E

Ground Clearance

1.22ft in

Loader

G

Clearance at Max Dump Height

9ft in

H

Reach at Max Dump Height

2.21ft in

I

Dig Depth

3.8in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

Family IV 445TA/E3, Tier III certified

Gross Power

110hp

Net Power

108.7hp

Power Measured @

2200rpm

Torque Measured @

1400rpm

Net Torque Rise

45%

Net Max Torque

372lb ft

Aspiration

turbocharged

Displacement

272cu in

Operational

Operating Weight 2wd

15268lb

Max Weight

19578lb

Fuel Capacity

42gal

Hydraulic System Fluid Capacity

32.3gal

Oil System Fluid Capacity

3.6gal

Cooling System Fluid Capacity

4.8gal

Transmission Fluid Capacity

5.2gal

Front Axle Fluid Capacity

1.8gal

Rear Axle Fluid Capacity

5gal

Turning Radius

12.4ft in

Tire Size Front - 2wd / 4wd

14.5/75x16.1/14x17.5

Rear Tires Size 2wd/4wd

21Lx24/21Lx24

Operating Voltage

12V

Alternator Supplied Amperage

90amps

Transmission

Transmission Type

4-speed synchromesh with hydraulically actuated clutches

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

24.6mph

Max Speed Reverse

29.5mph

Backhoe

Dig Depth - Std

16ft in

Dig Depth - Ext

20ft in

Reach From Swivel - Std

19.7ft in

Reach From Swivel - Ext

23.6ft in

Bucket Dig Force - Std

14718lb

Bucket Dig Force - Ext

14718lb

Load at Max Lift - Std

2870lb

Load at Max Lift - Ext

1940lb

Load Height - Std

11.5ft in

Load Height - Ext

13.8ft in

Reach at Load Height - Std

9.5ft in

Reach at Load Height - Ext

12.8ft in

Loader

Bucket Capacity

1.3yd3

Bucket Width

93in

Bucket Breakout Force

10729lb

Lift Capacity at Full Height

7327lb

Clearance at Max Dump Height

9ft in

Reach at Max Dump Height

2.3ft in

Dig Depth

3.8in

Hydraulic

Pump Type

Gear-type tandem

Pump Flow Capacity

42.5gal/min

Relief Valve Pressure

3050psi

Dimensions

Transport Length

23.6ft in

Transport Width

7.8ft in

Transport Height

11.2ft in

Height to Top of Suspended Cab

8.9ft in

Wheelbase

7.1ft in

Ground Clearance

1.3ft in
