Manitou MT 625 H Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
12.8ft in
E
Ground Clearance
1.09ft in
B
Width Over Tires
5.94ft in
C
Overall Height
6.3ft in
D
Wheelbase
7.55ft in
Turning Radius Outside Tires
10.86ft in
Lift
F
Max Lift Height
19.2ft in
Lowering Time - Unladen
5.4sec
Boom Retraction Time - Unladen
4.3sec
Crowd
3.5sec
Dump
3.6sec
Lifting Time - Unladen
8sec
Boom Extension Time - Unladen
5.6sec
Max Lift Capacity
5511.56lb
Specifications
Engine
Transmission Type
Hydrostatic
Number Of Cylinders
4
Engine Make
Kubota
Engine Model
V3307-DI-T-E4B
Gross Power
75hp
Cooling System
Water
Max Torque
195.5lb ft
Displacement
203.3cu in
Fuel Type
Diesel
Emission Level
Stage IV / Tier 4 Final
Injection
Direct
Operational
Operating Weight
5511.6lb
Hydraulic System Fluid Capacity
30.4gal
Tire Size
12-16.5 12PR SKS CL TUBELESS
Transmission
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed - Forward
15.6mph
Hydraulic
Pump Type
gear type with priority valve
Pump Flow Capacity
23.8gal/min
Relief Valve Pressure
3408.4psi
