John Deere 824K-II Wheel Loader
Units
Dimensions
Bucket
Breakout - Bucket
18718 (41266) kgf (lbf)
Bucket Capacity - Smallest
6.02yd3
Largest Bucket Capacity
6.81yd3
Dimensions
E
Ground Clearance
18.19in
A
Length With Bucket On Ground
30.45ft in
B
Width Over Tires
10.12ft in
D
Wheelbase
11.36ft in
F
Hinge Pin - Max Height
14.7ft in
H
Reach At Max Lift And Dump
6.73ft in
Turning Circle
47.05ft in
Height Over Cab
11.65ft in
Specifications
Engine
Pump
Piston
Engine Output-Net
332.6hp
Transmission Type
Powershift
Engine Make
John Deere
Engine Model
PowerTech PSS 6135
Torque
1206lb ft
Rated Speed
1500rpm
Displacement
823.9cu in
Torque Rise
57%
System Voltage
24V
Emission Level
Tier 4
Alternator
130amps
Driveline
Ride Control System
Yes
Service Brake Type
Wet Disc
Parking Brake Type
Wet Multi Disc
Differential Lock
Front- Locking, Rear- Open
Service Brake Actuation
Hydraulic
Tire Size - Standard
26.5 R25
Service Brake - Location
All Wheels
Capacities
Hydraulic Tank
43.6gal
Heaped Capacity
6.1yd3
Transmission
7.4gal
Operational
Operating Weight
59083.9lb
Fuel Capacity
126.1gal
Front Axle/Diff Fluid Capacity
14.7gal
Rear Axle/Diff Fluid Capacity
14.7gal
Transmission
Pump Flow
129.8gal/min
System Pressure
251.7psi
