John Deere 744H Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.99ft in
Bucket Capacity - Heaped
5.25yd3
Bucket Capacity - Struck
5yd3
Bucket Width
9.98ft in
Breakout Force
37821lb
Dimensions
E
Ground Clearance
1.53ft in
A
Length With Bucket On Ground
28.17ft in
B
Width Over Tires
9.65ft in
C
Height To Top Of Cab
11.55ft in
D
Wheelbase
11.16ft in
F
Hinge Pin - Max Height
14.05ft in
H
Reach At Max Lift And Dump
4.17ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6125A
Net Power
260hp
Gross Power
283hp
Power Measured @
2000rpm
Max Torque
943lb ft
Displacement
766cu in
Torque Measured @
1500rpm
Aspiration
Turbocharged and Aftercooled
Torque Rise
45%
Operational
Operating Weight
50298.5lb
Fuel Capacity
114gal
Hydraulic System Fluid Capacity
38gal
Engine Oil Fluid Capacity
10.1gal
Cooling System Fluid Capacity
11.4gal
Transmission Fluid Capacity
7.4gal
Front Axle/Diff Fluid Capacity
12.2gal
Rear Axle/Diff Fluid Capacity
12.2gal
Static Tipping Weight
37897.5lb
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Rear Axle Oscillation
26degrees
Tire Size
26.5-25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
24.5mph
Max Speed - Reverse
19.3mph
Hydraulic System
Relief Valve Setting
3200psi
Pump Flow Capacity
104gal/min
Raise Time
6.6sec
Dump Time
1.5sec
Lower Time
3sec
Pump Type
Piston Pump
