John Deere 1010D Four-Wheel Short Frame Forwarder

John Deere 1010D Four-Wheel Short Frame Forwarder Specs front
John Deere 1010D Four-Wheel Short Frame Forwarder Specs front
John Deere 1010D Four-Wheel Short Frame Forwarder Specs back
John Deere 1010D Four-Wheel Short Frame Forwarder Specs back
John Deere 1010D Four-Wheel Short Frame Forwarder Specs extended
John Deere 1010D Four-Wheel Short Frame Forwarder Specs extended
Units

Dimensions

Dimensions

A

Length

24.41 ft in

B

Width Over Tires

8.5 ft in

C

Height to Top of crane

12.17 ft in

D

Wheelbase

12.21 ft in

E

Ground Clearance

1.99 ft in

F

Length of Bunk Area

9.68 ft in

G

Width of Bunk Area

8.47 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2240

Engine Model

4045H

Power

115 hp

Torque

367 lb ft

Power Measured @

2000 rpm

Displacement

276 cu in

Torque Measured @

1400 rpm

Aspiration

turbocharged

Operational

Operating Weight - 4wd

27557.8 lb

Fuel Capacity

29.9 gal

Hydraulic System Fluid Capacity

50.2 gal

Operating Voltage

24 V

Alternator Supplied Amperage

100 amps

Front/Rear Tire Size - 4wd

600x34/14

Transmission

Transmission Type

hydrostatic/mechanical

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed

13.7 mph

Hydraulic

Pump Type

variable displacement

Flow Capacity

39.7 gal/min

Relief Valve Pressure

3481 psi

Bunk

Load Weight - 4wd

19842 lb

Load Area

36.6 ft2

Crane

Crane Type

Timberjack CF 5 72

Max Reach

23.7 ft in

Gross Lift Torque

75231.4 lb ft

Gross Slew Torque

18000 lb ft

Dimensions

Length

24.5 ft in

Width Over Tires

8.5 ft in

Height to Top of Crane

12.2 ft in

Wheelbase

12.3 ft in

Ground Clearance

2 ft in

Length of Bunk Area

9.7 ft in

Width of Bunk Area

8.5 ft in
