JCB 411ZX Direct Wheel Loader

JCB 411ZX Direct Wheel Loader Specs front
JCB 411ZX Direct Wheel Loader Specs front
JCB 411ZX Direct Wheel Loader Specs side
JCB 411ZX Direct Wheel Loader Specs side
JCB 411ZX Direct Wheel Loader Specs back
JCB 411ZX Direct Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.11 ft in

Dimensions

A

Length with Bucket on Ground

18.15 ft in

C

Height to Top of Cab

9.42 ft in

D

Wheelbase

7.39 ft in

E

Ground Clearance

1.42 ft in

F

Hinge Pin - Max Height

10.72 ft in

H

Reach at Max Lift and Dump

2.32 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2257

Engine Model

1004-42

Net Power

92 hp

Gross Power

86 hp

Power Measured @

2000 rpm

Displacement

258.3 cu in

Torque Measured @

1400 rpm

Max Torque

273.7

Aspiration

turbo

Operational

Operating Weight

16799.3 lb

Fuel Capacity

29.1 gal

Hydraulic System Fluid Capacity

34.4 gal

Engine Oil Fluid Capacity

2.9 gal

Cooling System Fluid Capacity

4.8 gal

Front Axle/Diff Fluid Capacity

4.3 gal

Rear Axle/Diff Fluid Capacity

4.8 gal

Static Tipping Weight

11464.1 lb

Turning Radius

15 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Rear Axle Oscillation

18 degrees

Transmission

Transmission Type

hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - Forward

12.5 mph

Max Speed - Reverse

12.5 mph

Hydraulic System

Pump Type

gear

Relief Valve Setting

3553

Pump Flow Capacity

23.8 gal/min

Raise Time

4.9 sec

Dump Time

0.9 sec

Lower Time

3.1 sec

Bucket

Breakout Force

17310.3 lb

Dump Clearance at Max Raise

9.2 ft in

Bucket Width

7.4 ft in

Bucket Capacity - heaped

1.6 yd3

Bucket Capacity - struck

1.4 yd3

Dimensions

Length with Bucket on Ground

18.2 ft in

Height to Top of Cab

9.5 ft in

Ground Clearance

1.5 ft in

Wheelbase

7.4 ft in

Hinge Pin - Max Height

10.8 ft in

Reach at Max Lift and Dump

2.4 ft in
