Ingersoll Rand VR518 Telescopic Forklift

Ingersoll Rand VR518 Telescopic Forklift Specs front
Ingersoll Rand VR518 Telescopic Forklift Specs front
Ingersoll Rand VR518 Telescopic Forklift Specs side
Ingersoll Rand VR518 Telescopic Forklift Specs side
Ingersoll Rand VR518 Telescopic Forklift Specs extended
Ingersoll Rand VR518 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

14.51 ft in

B

Width Over Tires

6.5 ft in

C

Overall Height

6.92 ft in

D

Wheelbase

8.17 ft in

E

Ground Clearance

55.99 ft in

Lift

F

Max Lift Height

18.34 ft in

G

Max Forward Reach

10.67 ft in


Specifications

Engine

Engine Make

2351

Engine Model

1004.40T

Gross Power

99 hp

Operational

Operating Weight

5011.2 lb

Fuel Capacity

38.4 gal

Operating Voltage

12 V

Drawbar Pull

8317 lb

Transmission

Transmission Type

hydrostatic with inching

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - forward

4.8 mph

Max Speed - reverse

4.8 mph

Lift

Max Lift Capacity

5011.2 lb

Max Lift Height

18.4 ft in

Max Load at Max Height

5011.2 lb

Max Forward Reach

10.7 ft in

Max Load at Max Reach

2004.1 lb

Dimensions

Length to Fork Face

14.6 ft in

Width Over Tires

6.5 ft in

Overall Height

7 ft in

Wheelbase

8.2 ft in

Ground Clearance

56 ft in

Turning Radius Outside Tires

12.4 ft in
