IHI 9NX-2 Mini Excavator

IHI 9NX-2 Mini Excavator Specs front
IHI 9NX-2 Mini Excavator Specs front
IHI 9NX-2 Mini Excavator Specs side
IHI 9NX-2 Mini Excavator Specs side
IHI 9NX-2 Mini Excavator Specs extended
IHI 9NX-2 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

8.83 ft in

C

Shipping Height of Unit

6.83 ft in

I

Max Cutting Height

9 ft in

J

Max Loading Height

9.75 ft in

L

Max Vertical Wall Digging Depth

3.83 ft in

M

Max Digging Depth

5.17 ft in

Dimensions

B

Width to Outside of Tracks

2.27 ft in

G

Height to Top of Cab

6.83 ft in

Undercarriage

F

Track Gauge

1.7 ft in

N

Shoe Size

7 in


Specifications

Engine

Engine Make

2348

Engine Model

2TNV70

Gross Power

10 hp

Operational

Operating Weight

2060 lb

Fuel Capacity

2.2 gal

Hydraulic System Relief Valve Pressure

2350 psi

Hydraulic Pump Flow Capacity

5.9 gal/min

Swing Mechanism

Swing Speed

8.7 rpm

Undercarriage

Shoe Size

7 in

Ground Pressure

3.8 psi

Max Travel Speed

2.2 mph

Track Gauge

1.7 ft in

Buckets

Reference Bucket Capacity

0.1 yd3

Boom/Stick Option (HEX) 1

Shipping Height of Unit

6.9 ft in

Shipping Length of Unit

8.9 ft in

Max Digging Depth

5.2 ft in

Max Cutting Height

9 ft in

Max Loading Height

9.8 ft in

Max Vertical Wall Digging Depth

3.9 ft in

Dimensions

Width to Outside of Tracks

2.3 ft in

Height to Top of Cab

6.9 ft in

Removal Counterweight Clearance

1.4 ft in
