Hitachi ZX10U-2 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
9.75ft in
I
Max Cutting Height
9.88ft in
C
Shipping Height Of Unit
4.76ft in
J
Max Loading Height
7.29ft in
L
Max Vertical Wall Digging Depth
5.48ft in
M
Max Digging Depth
5.84ft in
Boom/Stick Option (Hex) 1
Boom 1460mm/Stick 810mm
Dimensions
B
Width To Outside Of Tracks
3.29ft in
D
Length Of Track On Ground
3.42ft in
E
Ground Clearance
0.43ft in
G
Height To Top Of Cab
7.06ft in
H
Tail Swing Radius
2.73ft in
Undercarriage
N
Shoe Size
7.09in
F
Track Gauge
2.7ft in
Ground Pressure
3.49psi
Number Of Track Rollers Per Side
3
Max Travel Speed
2.49mph
Specifications
Engine
Number Of Cylinders
3
Engine Make
2348
Engine Model
3TNV70
Net Power
12.8hp
Power Measured @
2100rpm
Displacement
52.2cu in
Max Torque
37.3lb ft
Torque Measured @
1500rpm
Operational
Operating Weight
2447.2lb
Fuel Capacity
4.3gal
Cooling System Fluid Capacity
0.9gal
Hydraulic System Fluid Capacity
4.8gal
Engine Oil Capacity
0.8gal
Operating Voltage
12V
Hydraulic System Relief Valve Pressure
2567.2psi
Hydraulic Pump Flow Capacity
5.7gal/min
Swing Mechanism
Swing Speed
8.5rpm
Buckets
Reference Bucket Capacity
0.1yd3
