Hyundai R450LC-7A Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (Hex) 1

A

Shipping Length Of Unit

40.13ft in

C

Shipping Height Of Unit

12.54ft in

I

Max Cutting Height

34.78ft in

J

Max Loading Height

23.59ft in

K

Max Reach Along Ground

35.9ft in

L

Max Vertical Wall Digging Depth

19.66ft in

M

Max Digging Depth

22.35ft in

Boom/Stick Option (Hex) 1

Boom 23'2" (7060mm)/Stick 7'10" (2400mm)

Boom/Stick Option (Hex) 2

A

Shipping Length Of Unit

39.9ft in

I

Max Cutting Height

34.62ft in

C

Shipping Height Of Unit

12.31ft in

J

Max Loading Height

23.76ft in

K

Max Reach Along Ground

37.21ft in

L

Max Vertical Wall Digging Depth

19.2ft in

M

Max Digging Depth

23.99ft in

Boom/Stick Option (Hex) 2

Boom 23'2" (7060mm)/Stick 9'6" (2900mm)

Boom/Stick Option (Hex) 3

A

Shipping Length Of Unit

39.38ft in

I

Max Cutting Height

36.19ft in

J

Max Loading Height

25.14ft in

C

Shipping Height Of Unit

11.82ft in

K

Max Reach Along Ground

39.05ft in

L

Max Vertical Wall Digging Depth

21.53ft in

M

Max Digging Depth

25.56ft in

Boom/Stick Option (Hex) 3

Boom 23'2" (7060mm)/Stick 11'1" (3380mm)

Boom/Stick Option (Hex) 4

A

Shipping Length Of Unit

39.28ft in

C

Shipping Height Of Unit

13.26ft in

I

Max Cutting Height

36.91ft in

J

Max Loading Height

25.86ft in

K

Max Reach Along Ground

40.92ft in

M

Max Digging Depth

27.6ft in

Boom/Stick Option (Hex) 4

Boom 23'2" (7060mm)/Stick 13'1" (4000mm)

Max Vertical Wall Dig Depth

23.92ft in

Boom/Stick Option (Hex) 5

A

Shipping Length Of Unit

39.08ft in

C

Shipping Height Of Unit

14.74ft in

I

Max Cutting Height

37.73ft in

J

Max Loading Height

26.65ft in

K

Max Reach Along Ground

42.52ft in

M

Max Digging Depth

29.24ft in

Boom/Stick Option (Hex) 5

Boom 23'2" (7060mm)/Stick 14'9" (4500mm)

Max Vertical Wall Dig Depth

25.23ft in

Boom/Stick Option (Hex) 6

I

Max Cutting Height

33.5ft in

J

Max Loading Height

22.35ft in

A

Shipping Length Of Unit

38.49ft in

K

Max Reach Along Ground

34.03ft in

C

Shipping Height Of Unit

13.19ft in

M

Max Digging Depth

20.77ft in

Boom/Stick Option (Hex) 6

Boom 21'6" (6550mm)/Stick 7'10" (2400mm)

Max Vertical Wall Dig Depth

17.82ft in

Dimensions

E

Ground Clearance

1.83ft in

G

Height To Top Of Cab

10.67ft in

B

Width To Outside Of Tracks

10.96ft in

D

Length Of Track On Ground

13.26ft in

H

Tail Swing Radius

12.21ft in

Removal Counterweight Clearance

4.4ft in

Undercarriage

F

Track Gauge

8.99ft in

N

Shoe Size

23.63in

Ground Pressure

11.09psi

Max Travel Speed

3.11mph

Drawbar Pull

84800lb

Number Of Track Rollers Per Side

9

Number Of Shoes Per Side

53

Number Of Carrier Rollers Per Side

2


Specifications

Engine

Number Of Cylinders

6

Engine Make

2347

Engine Model

QSM11

Gross Power

357hp

Net Power

320hp

Power Measured @

1900rpm

Max Torque

1234lb ft

Displacement

659cu in

Aspiration

turbocharged

Torque Measured @

1400rpm

Operational

Operating Weight

99700lb

Fuel Capacity

161.2gal

Cooling System Fluid Capacity

13.3gal

Hydraulic System Fluid Capacity

100.4gal

Operating Voltage

24V

Engine Oil Capacity

10.1gal

Swing Drive Fluid Capacity

1.4gal

Alternator Supplied Amperage

50amps

Hydraulic System Relief Valve Pressure

5120psi

Hydraulic Pump Flow Capacity

190.3gal/min

Swing Mechanism

Swing Speed

9rpm

Buckets

Reference Bucket Capacity

2.9yd3

Minimum Bucket Capacity

1.9yd3

Maximum Bucket Capacity

4.2yd3
