Hyundai HL770XTD-7 Wheel Loader

Hyundai HL770XTD-7 Wheel Loader Specs front
Hyundai HL770XTD-7 Wheel Loader Specs front
Hyundai HL770XTD-7 Wheel Loader Specs side
Hyundai HL770XTD-7 Wheel Loader Specs side
Hyundai HL770XTD-7 Wheel Loader Specs back
Hyundai HL770XTD-7 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

11.72 ft in

Dimensions

A

Length with Bucket on Ground

29.86 ft in

B

Width Over Tires

9.77 ft in

C

Height to Top of Cab

11.65 ft in

D

Wheelbase

11.29 ft in

E

Ground Clearance

1.58 ft in

F

Hinge Pin - Max Height

15.62 ft in

H

Reach at Max Lift and Dump

4.14 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

QSC8.3-C

Net Power

266 hp

Gross Power

280 hp

Power Measured @

2200 rpm

Displacement

506.5 cu in

Torque Measured @

1400 rpm

Max Torque

1000

Aspiration

turbocharged

Operational

Operating Weight

51918.9 lb

Fuel Capacity

113.6 gal

Hydraulic System Fluid Capacity

84.6 gal

Engine Oil Fluid Capacity

5.3 gal

Cooling System Fluid Capacity

14.8 gal

Transmission Fluid Capacity

13.8 gal

Front Axle/Diff Fluid Capacity

20.7 gal

Rear Axle/Diff Fluid Capacity

14.1 gal

Static Tipping Weight

34130 lb

Operating Voltage

24 V

Alternator Supplied Amperage

70 amps

Rear Axle Oscillation

26 degrees

Tire Size

26.5-25 20PR L3

Transmission

Transmission Type

fully automatic power shift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

23.7 mph

Max Speed - Reverse

16.4 mph

Hydraulic System

Pump Type

open-centered, tandem circuit system

Relief Valve Setting

2990

Pump Flow Capacity

108.6 gal/min

Raise Time

5.7 sec

Dump Time

1.4 sec

Lower Time

2.8 sec

Bucket

Breakout Force

45040 lb

Dump Clearance at Max Raise

11.8 ft in

Bucket Width

10.2 ft in

Bucket Capacity - heaped

5.3 yd3

Bucket Capacity - struck

4.6 yd3

Dimensions

Length with Bucket on Ground

29.9 ft in

Width Over Tires

9.8 ft in

Height to Top of Cab

11.7 ft in

Ground Clearance

1.6 ft in

Wheelbase

11.3 ft in

Hinge Pin - Max Height

15.7 ft in

Reach at Max Lift and Dump

4.2 ft in
