Holland Lift Y83EL12 Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
9.68in
D
Wheelbase
6.67ft in
B
Overall Width
3.81ft in
C
Height W/ Rails
7.91ft in
E
Ground Clearance
3.55in
Height W/O Rails
5.06ft in
Platform
F
Max Platform Height
27.24ft in
I
Deck Extension
35.44in
Max Working Height
33.8ft in
Max Platform Weight Capacity
771.62lb
Lower Time
24sec
Platform Inner Length
104.34in
Platform Inner Width
44.89in
Lift Time
38sec
Specifications
Engine
Engine Make
0
System Voltage
24V
Battery Amp Hours
180
Operational
Operating Weight
5114.8lb
Max Speed
2.2mph
Tire Size
18x7x12.125
