Hitachi ZX350LCH-3 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
36.09ft in
C
Shipping Height Of Unit
10.73ft in
I
Max Cutting Height
33.99ft in
J
Max Loading Height
23.76ft in
K
Max Reach Along Ground
35.73ft in
L
Max Vertical Wall Digging Depth
21.07ft in
M
Max Digging Depth
24.22ft in
Boom/Stick Option (Hex) 1
Arm - 3.20 m H-arm
Dimensions
E
Ground Clearance
1.65ft in
G
Height To Top Of Cab
10.37ft in
B
Width To Outside Of Tracks
10.47ft in
D
Length Of Track On Ground
16.25ft in
H
Tail Swing Radius
11.13ft in
Removal Counterweight Clearance
3.81ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
23.63in
Number Of Shoes Per Side
48
Max Travel Speed
3.11mph
Number Of Track Rollers Per Side
8
Ground Pressure
9.29psi
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
Isuzu
Engine Model
AH-6HK1X
Net Power
270.9hp
Power Measured @
1900rpm
Max Torque
796.6lb ft
Aspiration
Turbocharged
Torque Measured @
1500rpm
Operational
Operating Weight
75398.1lb
Fuel Capacity
166.5gal
Cooling System Fluid Capacity
8.5gal
Hydraulic System Fluid Capacity
98.9gal
Operating Voltage
24V
Engine Oil Capacity
10.9gal
Swing Drive Fluid Capacity
4.5gal
Hydraulic Pump Flow Capacity
152.2gal/min
Swing Mechanism
Swing Speed
10.7rpm
Swing Torque
87032.4lb ft
