Haulotte Compact 3347E Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
98.4in
D
Wheelbase
6.1ft in
B
Overall Width
3.11ft in
E
Ground Clearance
6in
Overall Height
7.1ft in
Gradeability
23%
Tilt Alarm
2degrees
Turning Radius
8.2ft in
Platform
F
Max Platform Height
32.9ft in
I
Deck Extension
36in
Lift Time
58sec
Platform Extension Length
3ft in
Platform Length - Outside
7.7ft in
Platform Width - Outside
3.11ft in
Extended Platform Length
10.7ft in
Max Working Height
38.9ft in
Max Platform Weight Capacity
660lb
Lower Time
52sec
Specifications
Engine
System Voltage
24V
Battery Amp Hours
310
Operational
Operating Weight
5466lb
Hydraulic System Fluid Capacity
7gal
Max Speed
1.8mph
Tire Size
15x5
Tire Fill/Type
Foam
