Grove TM225T 8x4 drive Hydraulic Truck Crane

Hydraulic Truck Crane
Hydraulic Truck Crane
Hydraulic Truck Crane
Hydraulic Truck Crane
Hydraulic Truck Crane
Hydraulic Truck Crane
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

26 ft in

J

Max Height @ Max Raise Angle - no jib

80 ft in

K

Min Working Radius

10 ft in

L

Max Working Radius

75 ft in

M

Max Elevating Angle

75 degrees

Dimensions

A

Transport Length

31 ft in

C

Transport Height

11.92 ft in

E

Ground Clearance

1.04 ft in

F

Width w/ Outriggers Extended

15 ft in

G

Carrier Length

29.92 ft in

H

Upper Structure Tail Swing Radius

7.71 ft in


Specifications

UPPER STRUCTURE ENGINE

Make

Grove

Model

361

Gross Power

168 hp

Power Measured @

2800 rpm

Max Torque

330 lb ft

Torque Measured @

2000 rpm

CARRIER ENGINE

Make

Grove

Model

RD-501

Gross Power

214.8 hp

Power Measured @

3000 rpm

Max Torque

451 lb ft

Torque Measured @

1600 rpm

Displacement

501 cu in

Operational

Operating Weight

57000 lb

Number of Axels

4

Carrier Fuel Capacity

60 gal

Operating Voltage

12 V

Alternator Supplied Amperage

37 amps

Tire Size

11.00x20,12ply

Transmission

Transmission Type

Fuller

Number of Forward Gears

5

Number of Reverse Gears

1

Max Speed - Forward

51.8 mph

Max Speed - Reverse

6.4 mph

Boom

Number of Sections

4

Min Height @ Max Raise Angle

26 ft in

Max Height @ Max Raise Angle - no jib

80 ft in

Max Elevating Angle

75 degrees

Max Lift Capacity

50000 lb

Min Working Radius

10 ft in

Max Working Radius

75 ft in

Swing Speed

2.5 rpm

Dimensions

Transport Length

31 ft in

Transport Height

12 ft in

Ground Clearance

1.1 ft in

Width w/ Outriggers Extended

15 ft in

Carrier Length

30 ft in

Upper Structure Tail Swing Radius

7.8 ft in
