Grove TM225T 6x4 drive Hydraulic Truck Crane

Grove TM225T 6x4 drive Hydraulic Truck Crane Specs front
Grove TM225T 6x4 drive Hydraulic Truck Crane Specs front
Grove TM225T 6x4 drive Hydraulic Truck Crane Specs side
Grove TM225T 6x4 drive Hydraulic Truck Crane Specs side
Grove TM225T 6x4 drive Hydraulic Truck Crane Specs extended
Grove TM225T 6x4 drive Hydraulic Truck Crane Specs extended
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

32 ft in

J

Max Height @ Max Raise Angle - no jib

84 ft in

K

Min Working Radius

10 ft in

L

Max Working Radius

75 ft in

M

Max Elevating Angle

75 degrees

Dimensions

A

Transport Length

30.08 ft in

F

Width w/ Outriggers Extended

15 ft in

G

Carrier Length

26.58 ft in

H

Upper Structure Tail Swing Radius

7.71 ft in


Specifications

UPPER STRUCTURE ENGINE

Make

Grove

Model

300

Gross Power

149 hp

Power Measured @

2800 rpm

Max Torque

284 lb ft

Torque Measured @

2000 rpm

CARRIER ENGINE

Make

Grove

Model

RD501

Gross Power

215 hp

Max Torque

451 lb ft

Displacement

501 cu in

Operational

Operating Weight

56300 lb

Number of Axels

3

Carrier Fuel Capacity

60 gal

Operating Voltage

12 V

Alternator Supplied Amperage

75 amps

Tire Size

11.00x20

Transmission

Number of Forward Gears

5

Number of Reverse Gears

1

Max Speed - Forward

49.1 mph

Max Speed - Reverse

6.4 mph

Boom

Number of Sections

4

Min Height @ Max Raise Angle

32 ft in

Max Height @ Max Raise Angle - no jib

84 ft in

Max Elevating Angle

75 degrees

Max Lift Capacity

50000 lb

Min Working Radius

10 ft in

Max Working Radius

75 ft in

Swing Speed

2.5 rpm

Dimensions

Transport Length

30.1 ft in

Width w/ Outriggers Extended

15 ft in

Carrier Length

26.6 ft in

Upper Structure Tail Swing Radius

7.8 ft in
