Genie S105 Boom Lift

Genie S105 Boom Lift Specs side
Genie S105 Boom Lift Specs side
Genie S105 Boom Lift Specs back
Genie S105 Boom Lift Specs back
Genie S105 Boom Lift Specs extended
Genie S105 Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

46 in

B

Overall Width

8.17 ft in

C

Overall Height - mast lowered

10.08 ft in

D

Wheelbase

12.01 ft in

E

Ground Clearance

1.74 in

Platform

F

Max Platform Height

104.99 ft in

G

Max Horizontal Reach

79.99 ft in


Specifications

Engine

Engine Make

2349

Engine Model

TD2011 L04i

Gross Power

74 hp

Fuel Type

diesel

Operational

Operating Weight

39700.9 lb

Fuel Capacity

34.9 gal

Hydraulic System Fluid Capacity

39.7 gal

Max Speed

3 mph

Tire Size

385/65D22.5

Platform

Max Working Height

111.6 ft in

Max Platform Height

105 ft in

Max Horizontal Reach

80 ft in

Max Platform Weight Capacity

500.5 lb

Platform Inner Length

96.1 in

Platform Inner Width

35.9 in

Platform Rotation

160 degrees

Dimensions

Wheelbase

12.1 ft in

Overall Length

46 in

Overall Width

8.2 ft in

Overall Height - mast lowered

10.1 ft in

Turning Radius

19.9 ft in

Ground Clearance

1.8 in
