Doosan 430 Plus Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10ft in
B
Width Over Tires
4.88ft in
E
Ground Clearance
7.49in
C
Height To Top Of Cab
6.35ft in
D
Wheelbase
3.14ft in
F
Length W/O Bucket
7.78ft in
G
Clearance At Max Lift And Dump
7.2ft in
H
Reach At Max Lift And Dump
20.4in
Turning Radius From Center - Machine Rear
60.4in
Turning Radius From Center - Inc Bucket
71.03in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2347
Engine Model
A2000
Net Power
45hp
Power Measured @
2800rpm
Displacement
122cu in
Operational
Operational Weight
5703lb
Fuel Capacity
14.1gal
Max Speed
7.5mph
Tire Size
10-16.5-6PR
Loader
Breakout Force
3139lb
Operating Load Rating
1505lb
Tipping Angle
3009degrees
Hydraulic
Pump Type
gear type
Pump Flow Capacity
11.8gal/min
Relief Valve Pressure
2537.5psi
