Mustang 2044 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.23ft in
B
Width Over Tires
5.34ft in
E
Ground Clearance
7.7in
C
Height To Top Of Cab
9.34ft in
D
Wheelbase
3.06ft in
F
Length W/O Bucket
7.94ft in
G
Clearance At Max Lift And Dump
7.36ft in
H
Reach At Max Lift And Dump
88.2in
Turning Radius From Center - Machine Rear
50.5in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV88
Net Power
47hp
Power Measured @
3000rpm
Displacement
133.6cu in
Operational
Operational Weight
5600lb
Fuel Capacity
14.3gal
Hydraulic System Fluid Capacity
13gal
Max Speed
7mph
Operating Voltage
12V
Alternator Supplied Amperage
700amps
Loader
Breakout Force
4000lb
Operating Load Rating
1500lb
Tipping Angle
2900degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
18gal/min
Relief Valve Pressure
2500psi
