Caterpillar D8R LGP Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length W/ Blade

20.61ft in

B

Width Over Tracks

10.84ft in

C

Height To Top Of Cab

11.46ft in

D

Length Of Track On Ground

10.69ft in

E

Ground Clearance

1.71ft in

F

Length W/O Blade

14.95ft in

Undercarriage

G

Track Gauge

7.67ft in

H

Standard Shoe Size

38in

Number Of Shoes Per Side

44

Ground Pressure

7.6psi

Ground Contact Area

9746in2

Number Of Track Rollers Per Side

8

Track Pitch

8.51in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2236

Engine Model

3406C

Gross Power

328hp

Net Power

305hp

Power Measured @

2100rpm

Displacement

893cu in

Aspiration

Turbocharged and Aftercooled

Operational

Operating Weight

74360lb

Fuel Capacity

165.2gal

Cooling System Fluid Capacity

24.4gal

Engine Oil Capacity

8.6gal

Hydraulic Fluid Capacity

19.1gal

Powertrain Fluid Capacity

38.1gal

Final Drives Fluid Capacity

3.7gal

Operating Voltage

24V

Alternator Supplied Amperage

50amps

Transmission

Transmission Type

Power Shift

Number Of Forward Gears

3

Number Of Reverse Gears

3

Max Speed - Forward

6.7mph

Max Speed - Reverse

8.6mph

Hydraulic System

Pump Type

Piston

Relief Valve Pressure

3500psi

Pump Flow Capacity

79.3gal/min

Standard Blade

Width

14.5ft in

Height

63.5in

Capacity

11.2yd3

Cutting Depth

23in
