Caterpillar D4B Crawler Tractor

Caterpillar D4B Crawler Tractor Specs front
Caterpillar D4B Crawler Tractor Specs front
Caterpillar D4B Crawler Tractor Specs side
Caterpillar D4B Crawler Tractor Specs side
Caterpillar D4B Crawler Tractor Specs back
Caterpillar D4B Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

12.18 ft in

B

Width Over Tracks

5.84 ft in

C

Height to Top of Cab

8.75 ft in

D

Length of Track on Ground

6.76 ft in

E

Ground Clearance

0.96 ft in

F

Length w/o Blade

9.09 ft in

Undercarriage

G

Track Gauge

4.67 ft in

H

Standard Shoe Size

15.99 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Engine Model

3204

Gross Power

81 hp

Net Power

75 hp

Power Measured @

2400 rpm

Displacement

317.4 cu in

Operational

Operating Weight

16422 lb

Fuel Capacity

30.7 gal

Cooling System Fluid Capacity

5.3 gal

Engine Oil Capacity

3.2 gal

Hydraulic Fluid Capacity

18.5 gal

Final Drives Fluid Capacity

2.2 gal

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Transmission

Transmission Type

Planetary Powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.9 mph

Max Speed - Reverse

7.4 mph

Undercarriage

Ground Pressure

6.4 psi

Ground Contact Area

2590 in2

Standard Shoe Size

16 in

Number of Shoes per Side

39

Track Gauge

4.7 ft in

Hydraulic System

Pump type

gear

Relief Valve Pressure

2500 psi

Pump Flow Capacity

14.6 gal/min

Standard Blade

Width

8 ft in

Height

36.6 in

Capacity

2 yd3

Blade Angle (both directions)

25 degrees

Cutting Depth

15 in

Dimensions

Length w/o Blade

9.1 ft in

Length w/ Blade

12.2 ft in

Width Over Tracks

5.9 ft in

Height to Top of Cab

8.8 ft in

Length of Track on Ground

6.8 ft in

Ground Clearance

1 ft in


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Ground Pressure

Net Power

74 hp

Operating Weight

16250 lb

Ground Pressure

6.2 psi

Net Power

75 hp

Operating Weight

15720 lb

Ground Pressure

6.3 psi

Net Power

74 hp

Operating Weight

17185 lb

Ground Pressure

6.5 psi
