Caterpillar D3B LGP-S Crawler Tractor

Caterpillar D3B LGP-S Crawler Tractor Specs front
Caterpillar D3B LGP-S Crawler Tractor Specs front
Caterpillar D3B LGP-S Crawler Tractor Specs side
Caterpillar D3B LGP-S Crawler Tractor Specs side
Caterpillar D3B LGP-S Crawler Tractor Specs back
Caterpillar D3B LGP-S Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

13.7 ft in

B

Width Over Tracks

9.85 ft in

C

Height to Top of Cab

8.99 ft in

D

Length of Track on Ground

8.04 ft in

E

Ground Clearance

1.19 ft in

F

Length w/o Blade

11.13 ft in

Undercarriage

G

Track Gauge

6.6 ft in

H

Standard Shoe Size

38.98 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Engine Model

3204

Net Power

65 hp

Power Measured @

2400 rpm

Displacement

317.4 cu in

Operational

Operating Weight

18642.3 lb

Fuel Capacity

30.2 gal

Cooling System Fluid Capacity

5.3 gal

Engine Oil Capacity

3.2 gal

Hydraulic Fluid Capacity

22.2 gal

Final Drives Fluid Capacity

3.2 gal

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Transmission

Transmission Type

Planetary powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.3 mph

Max Speed - Reverse

6.7 mph

Undercarriage

Ground Contact Area

7519.1 in2

Standard Shoe Size

39 in

Number of Shoes per Side

44

Number of Track Rollers per Side

7

Track Gauge

6.6 ft in

Hydraulic System

Pump type

Constant power

Relief Valve Pressure

2500 psi

Pump Flow Capacity

22 gal/min

Standard Blade

Width

11.5 ft in

Height

21.7 in

Cutting Depth

18 in

Dimensions

Length w/o Blade

11.2 ft in

Length w/ Blade

13.7 ft in

Width Over Tracks

9.9 ft in

Height to Top of Cab

9 ft in

Length of Track on Ground

8.1 ft in

Ground Clearance

1.2 ft in
