Caterpillar D3C XL Series III Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length w/ Blade

13.19 ft in

B

Width Over Tracks

6 ft in

C

Height to Top of Cab

8.75 ft in

D

Length of Track on Ground

6.75 ft in

E

Ground Clearance

0.99 ft in

F

Length w/o Blade

9.78 ft in

Undercarriage

G

Track Gauge

4.67 ft in

H

Standard Shoe Size

15.99 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

3046

Gross Power

78 hp

Net Power

71 hp

Power Measured @

2400 rpm

Displacement

305 cu in

Engine Model

Cat 3046

Power - Gross

78 hp

Power - Net

70 hp

Operational

Operating Weight

15941.7 lb

Fuel Capacity

32.2 gal

Cooling System Fluid Capacity

2.4 gal

Engine Oil Capacity

3.5 gal

Hydraulic Fluid Capacity

15.1 gal

Powertrain Fluid Capacity

7.5 gal

Final Drives Fluid Capacity

2.6 gal

Operating Voltage

12 V

Alternator Supplied Amperage

55 amps

Transmission

Transmission Type

Power Shift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.7 mph

Max Speed - Reverse

7.1 mph

Undercarriage

Ground Pressure

6.2 psi

Standard Shoe Size

16 in

Number of Shoes per Side

39

Number of Track Rollers per Side

6

Track Gauge

4.7 ft in

Weights

Operating Weight - XL

15941 lb

Hydraulic System

Pump type

Gear

Relief Valve Pressure

2500 psi

Pump Flow Capacity

14.3 gal/min

Standard Blade

Width

8.2 ft in

Height

33.2 in

Capacity

1.7 yd3

Blade Angle (both directions)

25 degrees

Cutting Depth

15.7 in

Dimensions

Overall Height

9 ft in

Length w/o Blade

9.8 ft in

Length w/ Blade

13.2 ft in

Width Over Tracks

6 ft in

Height to Top of Cab

8.8 ft in

Length of Track on Ground

6.8 ft in

Ground Clearance

1 ft in

Bulldozer Blade Width - Straight

8.4 ft in

Operating Specifications

Dig Depth - VPAT Blade

17 in

Lift Height - VPAT Blade

30 in

Maximum Tilt - VPAT Blade

14 in

Maximum Angle - VPAT Blade

25 degrees


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Ground Pressure

Net Power

70 hp

Operating Weight

15932 lb

Ground Pressure

6.6 psi

Net Power

71 hp

Operating Weight

15518 lb

Ground Pressure

6.5 psi

Net Power

70 hp

Operating Weight

15732 lb

Ground Pressure

6.5 psi
