Caterpillar D3C LGP-S Series II Crawler Tractor

Caterpillar D3C LGP-S Series II Crawler Tractor Specs front
Caterpillar D3C LGP-S Series II Crawler Tractor Specs front
Caterpillar D3C LGP-S Series II Crawler Tractor Specs side
Caterpillar D3C LGP-S Series II Crawler Tractor Specs side
Caterpillar D3C LGP-S Series II Crawler Tractor Specs back
Caterpillar D3C LGP-S Series II Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

13.72 ft in

B

Width Over Tracks

9.85 ft in

C

Height to Top of Cab

8.99 ft in

D

Length of Track on Ground

8.04 ft in

E

Ground Clearance

0.92 ft in

F

Length w/o Blade

11.16 ft in

Undercarriage

G

Track Gauge

6.57 ft in

H

Standard Shoe Size

38.98 in


Specifications

Engine

Engine Make

2236

Engine Model

3204

Gross Power

70 hp

Displacement

317.4 cu in

Operational

Operating Weight

18942.2 lb

Fuel Capacity

30.2 gal

Transmission

Transmission Type

powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.8 mph

Max Speed - Reverse

7.1 mph

Undercarriage

Ground Pressure

2.5 psi

Ground Contact Area

7517.6 in2

Standard Shoe Size

39 in

Number of Track Rollers per Side

7

Track Gauge

6.6 ft in

Standard Blade

Width

9.2 ft in

Height

29.1 in

Capacity

1.6 yd3

Cutting Depth

13.9 in

Dimensions

Length w/o Blade

11.2 ft in

Length w/ Blade

13.8 ft in

Width Over Tracks

9.9 ft in

Height to Top of Cab

9 ft in

Length of Track on Ground

8.1 ft in

Ground Clearance

1 ft in


Compare similar models

Manufacturer / Model

Operating Weight

Ground Pressure

Operating Weight

16997.7 lb

Ground Pressure

1.9 psi
