Caterpillar 554 Forwarder

Caterpillar 554 Forwarder Specs front
Caterpillar 554 Forwarder Specs front
Caterpillar 554 Forwarder Specs back
Caterpillar 554 Forwarder Specs back
Caterpillar 554 Forwarder Specs extended
Caterpillar 554 Forwarder Specs extended
Units

Dimensions

Dimensions

A

Length

28.34 ft in

B

Width Over Tires

8.5 ft in

C

Height to Top of crane

12.21 ft in

E

Ground Clearance

1.69 ft in

F

Length of Bunk Area

15.75 ft in

G

Width of Bunk Area

8.5 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3054 DITA

Power

111.4 hp

Torque

329 lb ft

Power Measured @

2200 rpm

Displacement

243 cu in

Torque Measured @

1600 rpm

Operational

Operating Weight - 8wd

28500 lb

Fuel Capacity

23.8 gal

Front/Rear Tire Size - 8wd

600/50-22.5 12PR B

Transmission

Transmission Type

Hydrostatic/Mechanical

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed

15.5 mph

Bunk

Load Weight - 8wd

22000 lb

Crane

Crane Type

F61 F72

Max Reach

23.5 ft in

Gross Lift Torque

15300 lb ft

Dimensions

Length

28.4 ft in

Width Over Tires

8.5 ft in

Height to Top of Crane

12.3 ft in

Ground Clearance

1.7 ft in

Length of Bunk Area

15.8 ft in

Width of Bunk Area

8.5 ft in
