Caterpillar 242B Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

11.28 ft in

B

Width Over Tires

5.5 ft in

C

Height to Top of Cab

6.52 ft in

D

Wheelbase

3.59 ft in

E

Ground Clearance

7 in

F

Length w/o Bucket

9.06 ft in

G

Clearance at Max Lift and Dump

7.45 ft in

H

Reach at Max Lift and Dump

30.16 in


Specifications

Engine

Engine Make

2236

Engine Model

3024C T

Gross Power

62 hp

Net Power

57.7 hp

Aspiration

turbocharged

Bore

3.3 in

Stroke

3.9 in

Gross Power - SAE J1995

62 hp

Engine Model

Cat 3024C T

Engine Power - ISO 14396

61 hp

Net Power - EEC 80/1269

57 hp

Net Power - ISO 9249 EEC

57 hp

Net Power - SAE 1349

57 hp

Net Flywheel Power

57 hp

Operational

Operational Weight

6801.3 lb

Fuel Capacity

17.2 gal

Cooling System Fluid Capacity

2.7 gal

Engine Oil Fluid Capacity

2.2 gal

Hydraulic System Fluid Capacity

14.6 gal

Chain Box Fluid Capacity - each side

1.6 gal

Max Speed

7.5 mph

Tire Size

12x16.5 10PR

Operating Voltage

12 V

Alternator Supplied Amperage

85 amps

Power Train

Travel Speed Forward

7.4 mph

Travel Speed Reverse

7.4 mph

Weights

Operating Weight

6802 lb

Operating Weight - HF

6895 lb

Loader

Breakout Force

4058.8

Operating Load Rating

1999.6 lb

Tipping Angle

3999.2 degrees

Hydraulic System

Hydraulic Flow (1)

Standard flow

Maximum Loader Hydraulic Flow

26 gal/min

Loader Hydraulic Pressure

3335 psi

Loader Hydraulic Flow

15.6 gal/min

Hydraulic Flow (2)

High Flow

Hydraulic Power (2)

50.6 hp

Hydraulic Power (1)

30.4 hp

Hydraulic

Pump Flow Capacity

15.9 gal/min

Relief Valve Pressure

3335.9 psi

Dimensions

Length with Bucket

11.3 ft in

Length w/o Bucket

9.1 ft in

Width Over Tires

5.5 ft in

Height to Top of Cab

6.6 ft in

Clearance at Max Lift and Dump

7.5 ft in

Wheelbase

3.6 ft in

Ground Clearance

7 in

Reach at Max Lift and Dump

30.2 in

Turning Radius from Center - machine rear

60.9 in

Turning Radius from Center - inc bucket

87.5 in

Wheel Base

3.6 ft in

Bucket Pin Height - Maximum Lift

10 ft in

Height - Top of Cab

6.5 ft in

Length - Without Bucket

109 in

Length - With Bucket on Ground

135 in

Maximum Overall Height

155 in

Bucket Pin Height - Carry Position

12 in

Clearance at Maximum Lift and Dump

88 in

Turn Radius from Center - Rear

60.8 in

Turn Radius from Center - Coupler

56.5 in

Turn Radius from Center - Bucket

87.4 in

Maximum Reach - With Arms Parallel

48.4 in

Reach - Maximum Lift/Dump

30 in

Vehicle Width over Tires

66 in

Bumper Overhang - Rear Axle

39 in

Operating Specifications

Rated Operating Capacity with Optional Counterweight

2047 lb

Tipping Load

4000 lb

Breakout Force - Tilt Cylinder

4059 lb

Breakout Force - Lift Cylinder

3841 lb

Rated Operating Capacity

2000 lb

Breakout Force - Lift Cylinder (HF)

3818 lb

Service Refill Capacities

Cooling System

2.6 gal

Fuel Tank

17 gal

Hydraulic Tank

9.2 gal

Engine Crankcase

2.1 gal

Hydraulic System

14.5 gal

Chain Box - Each Side

1.6 gal

Cab

ROPS

SAE J1040 MAY94 and ISO3471:1994

FOPS

SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I

FOPS Level II

SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional)
