Caterpillar 242 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
11.28ft in
B
Width Over Tires
5.01ft in
E
Ground Clearance
7in
C
Height To Top Of Cab
6.52ft in
D
Wheelbase
3.73ft in
F
Length W/O Bucket
9.11ft in
G
Clearance At Max Lift And Dump
7.47ft in
H
Reach At Max Lift And Dump
30.16in
Wheel Base
3.59ft in
Bucket Pin Height - Carry Position
11.8in
Clearance At Maximum Lift And Dump
88.2in
Length - Without Bucket
109.3in
Bucket Pin Height - Maximum Lift
10ft in
Maximum Overall Height
154.6in
Height - Top Of Cab
6.52ft in
Bumper Overhang - Rear Axle
38.9in
Reach - Maximum Lift/Dump
29.9in
Turning Radius From Center - Inc Bucket
88.71in
Length - With Bucket On Ground
135.31in
Vehicle Width Over Tires
66in
Operating Specifications
Breakout Force - Tilt Cylinder
4056lb
Breakout Force - Lift Cylinder
3814lb
Rated Operating Capacity
2000lb
Rated Operating Capacity With Optional Counterweight
2047lb
Tipping Load
4000lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3034
Gross Power
58hp
Net Power
54hp
Power Measured @
2600rpm
Displacement
183cu in
Bore
3.9in
Stroke
4in
Engine Model
Cat 3034C
Net Flywheel Power
54hp
Operational
Operational Weight
6931lb
Fuel Capacity
17.2gal
Max Speed
6.9mph
Hydraulic System Fluid Capacity
14.6gal
Operating Speed
6.9mph
Loader
Operating Load Rating
2000lb
Tipping Angle
3770degrees
Bucket Capacity
0.6yd3
Weights
Operating Weight
6858.5lb
Hydraulic
Pump Flow Capacity
15.2gal/min
Hydraulic System
Loader Hydraulic Pressure
3300 psi
Loader Hydraulic Flow
15.1 gal/min
Service Refill Capacities
Cooling System
24gal
Fuel Tank
18.2gal
Hydraulic Tank
9.2gal
Engine Crankcase
2.1gal
Hydraulic System
15.3gal
Chain Box - Each Side
1.6gal
Cab
Rops
SAE J1040 MAY94 and ISO3471:1994
Fops
SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I
Fops Level Ii
SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional)
