Case IH RMX370 25ft Disc
Units
Dimensions
Dimensions
A
Overall Length
23.25in
B
Transport Width
15.25ft in
C
Transport Height
11.92ft in
Operating Speed
7mph
Pto Power Required Per Width Ft.
8.6hp
Wing Tires
11L x 15 8PR
Main Frame Tires
12.5L x 15 FI
Working Width Spacing #1 Min
25.17ft in
Max Weight
18175lb
Min Weight
13306lb
Specifications
Disc System
Spacing #1
9in
Depth Control
Single Point Hydraulic
Weight Per Blade Spacing #1
190lb
Max Operating Depth
6in
Gangs
Gang Mounts
Rigid or C-Spring Cushion
Gang Arbor Bolts
1.5in
Gang Spool Type
Nodular Iron Spool
Gang Spool Diameter
6in
Front Disk Angle
18degrees
Rear Disk Angle
18degrees
Bearing Type
Regreasable Triple Lip, Heavy Steel Bearing, Self-aligning Flange Style
Scrapers
4 in. Heavy-duty Spring Steel
