Case 721FXR Wheel Loader

Case 721FXR Wheel Loader Specs front
Case 721FXR Wheel Loader Specs front
Case 721FXR Wheel Loader Specs side
Case 721FXR Wheel Loader Specs side
Case 721FXR Wheel Loader Specs back
Case 721FXR Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

10.91 ft in

Dimensions

A

Length with Bucket on Ground

26.27 ft in

B

Width Over Tires

8.71 ft in

C

Height to Top of Cab

11.11 ft in

D

Wheelbase

10.68 ft in

E

Ground Clearance

1.2 ft in

F

Hinge Pin - Max Height

14.36 ft in

H

Reach at Max Lift and Dump

3.7 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2562

Engine Model

F4HFE613Y

Net Power

179 hp

Gross Power

195 hp

Power Measured @

2000 rpm

Displacement

411 cu in

Torque Measured @

1300 rpm

Max Torque

674

Torque Rise

37 %

Aspiration

Turbocharged

Operational

Operating Weight

31991 lb

Fuel Capacity

65 gal

Hydraulic System Fluid Capacity

47 gal

Engine Oil Fluid Capacity

4 gal

Cooling System Fluid Capacity

7.6 gal

Transmission Fluid Capacity

9 gal

Front Axle/Diff Fluid Capacity

9.3 gal

Rear Axle/Diff Fluid Capacity

6.1 gal

Static Tipping Weight

22315 lb

Operating Voltage

24 V

Alternator Supplied Amperage

65 amps

Rear Axle Oscillation

24 degrees

Transmission

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

23.5 mph

Max Speed - Reverse

15.9 mph

Hydraulic System

Relief Valve Setting

3625

Pump Flow Capacity

54.5 gal/min

Raise Time

5.2 sec

Dump Time

1.3 sec

Lower Time

2.4 sec

Bucket

Dump Clearance at Max Raise

11 ft in

Bucket Width

8.9 ft in

Bucket Capacity - heaped

3.3 yd3

Dimensions

Length with Bucket on Ground

26.3 ft in

Width Over Tires

8.8 ft in

Height to Top of Cab

11.2 ft in

Ground Clearance

1.2 ft in

Wheelbase

10.7 ft in

Hinge Pin - Max Height

14.4 ft in

Reach at Max Lift and Dump

3.7 ft in
