Bolinder Munktell VHK55 Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

24.68ft in

B

Width Over Tires

7.32ft in

D

Wheelbase

18.05ft in

G

Tandem Axle Wheelbase

4.76ft in

H

Blade Base

7.75ft in


Specifications

Engine

Engine Model

D67

Net Power Gear 5-6

75hp

Max Power

75hp

Displacement

410.1cu in

Operational

Std Operation Weight - Front Axle

5643.9lb

Std Operation Weight - Rear Axle

14197.8lb

Std Operation Weight - Total

19841.7lb

Tire Size

13.00x24 12ply

Operating Voltage

24V

Transmission

Number of Gears - Forward

8

Number of Gears - Reverse

2

Max Speed - Forward

17.4mph

Max Speed - Reverse

3.9mph

Steering

Turning Radius

31.2ft in

Moldboard

Moldboard Width

10.1ft in

Moldboard Height

23.7in

Moldboard Thickness

0.8in

Side Shift Left

36.7in

Side Shift Right

36.7in

Blade Pull at Max Weight

7936.7lb

Circle

Diameter

58.6in

Rotation

360degrees

Max Reach Outside Tires - Left

56in

Max Reach Outside Tires - Right

56in

Max Lift Above Ground

19.7in

Blade Tip Angle - Front

45degrees

Dimensions

Height to Top of Isomount Cab

9.7ft in

Overall Length

24.7ft in

Width Over Tires

7.4ft in

Wheelbase

18.1ft in

Blade Base

7.8ft in

Tandem Axle Wheelbase

4.8ft in
