Astra ADT35C Articulated Dump Truck

Astra ADT35C Articulated Dump Truck Specs front
Astra ADT35C Articulated Dump Truck Specs front
Astra ADT35C Articulated Dump Truck Specs side
Astra ADT35C Articulated Dump Truck Specs side
Astra ADT35C Articulated Dump Truck Specs back
Astra ADT35C Articulated Dump Truck Specs back
Units

Dimensions

Dimensions

A

Overall Length

35.38 ft in

B

Overall Width

10.47 ft in

C

Overall Height

12.46 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2358

Engine Model

Cursor 13

Gross Power

405 hp

Power Measured @

2100 rpm

Displacement

781.2 cu in

Max Torque

1364.5 lb ft

Torque Measured @

1400 rpm

Operational

Tire Size

26.5R25

Transmission

Transmission Type

Auto

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed

31.5 mph

Weights

Total Empty

62831.8 lb

Dump

Rated Payload

69445.7 lb

Capacity - Heaped

26.2 yd3

Raise Time

11 sec

Lower Time

13 sec

Dimensions

Overall Length

35.4 ft in

Overall Width

10.5 ft in

Overall Height

12.5 ft in
