AAA 922hm Articulated Dump Truck

Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Units

Dimensions

Dimensions

A

Overall Length

11.6ft in

B

Overall Width

9ft in

C

Overall Height

11.4ft in

D

Wheelbase

146ft in

E

Ground Clearance

19ft in

Dump

H

Dump Angle

72degrees


Specifications

Engine

Number of Cylinders

6

Engine Model

Cummings QSB

Gross Power

264hp

Net Power

274hp

Power Measured @

2200rpm

Max Torque

990lb ft

Torque Measured @

1500rpm

Operational

Fuel Capacity

80gal

Hydraulic System Fluid Capacity

53gal

Engine Oil Capacity

6.7gal

Transmission Fluid Capacity

24gal

Alternator Supplied Amperage

70amps

Tire Size

3240

Transmission

Transmission Type

ZF Ergopower 6 WG 210

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed

31mph

Weights

Front Axle - empty

17630lb

Center Axle - empty

8600%

Rear Axle - empty

8600lb

Front Axle - loaded

23800%

Center Axle - loaded

27550%

Rear Axle - loaded

27550lb

Total Empty

35540lb

Total Loaded

44070lb

Dump

Capacity - Struck

11.6yd3

Capacity - Heaped

15.7yd3

Dump Angle

72degrees

Raise Time

7.5sec

Lower Time

5.5sec

Dimensions

Overall Length

11.6ft in

Overall Width

9ft in

Overall Height

11.4ft in

Wheelbase

146ft in

Ground Clearance

19ft in
