John Deere 300D Water Wagon Chassis Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
37.83ft in
B
Overall Width
11ft in
C
Overall Height
13.98ft in
D
Wheelbase
19.99ft in
E
Ground Clearance
1.56ft in
Dump
Rated Payload
59083.89lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6090
Net Power
285hp
Power Measured @
2200rpm
Max Torque
789lb ft
Torque Measured @
1400rpm
Aspiration
turbocharged charge air cooled
Displacement
549cu in
Operational
Fuel Capacity
90gal
Hydraulic System Fluid Capacity
20.8gal
Cooling System Fluid Capacity
8.7gal
Engine Oil Capacity
6.7gal
Transmission Fluid Capacity
5.8gal
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Tire Size
23.5R25
Transmission
Transmission Type
ZF 6HP592C Ecomat 2+ fully automatic
Number Of Forward Gears
6
Number Of Reverse Gears
1
Max Speed
31.1mph
Weights
Front Axle - Empty
23082.4lb
Rear Axle - Empty
26047.7lb
Front Axle - Loaded
31129.3%
Rear Axle - Loaded
77084.7lb
Total Empty
49130.1lb
Total Loaded
108213.9lb
