Wirtgen W120F Cold Planer

Cold Planer
Cold Planer
Cold Planer
Cold Planer
Cold Planer
Cold Planer
MODEL.UNITS

Dimensions

Conveyor System

H

Discharge Conveyor Width

23.63in

Collecting Conveyor Width

25.6in

Discharge Conveyor Swing (R/L)

36degrees

Dimensions

A

Operating Length

44.13ft in

B

Shipping Width

9.03ft in

C

Shipping Height

10.18ft in

D

Shipping Length

19.36ft in

E

Max Operating Height

18.05ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2347

Engine Model

QSC 8.3

Gross Power

304hp

Net Power

280hp

Power Measured @

2100rpm

Displacement

506.5cu in

Operational

Operating Weight - Full Load

47840.4lb

Shipping Weight - Empty

43431.1lb

Fuel Capacity

163.8gal

Hydraulic System Fluid Capacity

34.4gal

Water Spray System Fluid Capacity

369.9gal

Operational Voltage

24V

Operating Speed

105ft/min

Travel Speed

3.3mph

Rotary Cutter

Cutting Width

4ft in

Cutting Depth

12.6in

Cutter Diameter

38.6in

Number Of Tools

115

Tool Spacing

0.6in

Tracks

Number Of Track Units

4

Front Track Length

4.4ft in

Front Track Width

10.3in

Rear Track Length

4.4ft in

Rear Track Width

10.3in


MODEL.COMPARESIMILARM

MODEL.MANUFACTURERMOD

Cutting Width

Net Power

Operating Weight - Full Load

Cutting Width

4.3 ft in

Net Power

280 hp

Operating Weight - Full Load

48722.2 lb
