Volvo EC45 Pro Midi Excavator

Volvo EC45 Pro Midi Excavator Specs front
Volvo EC45 Pro Midi Excavator Specs front
Volvo EC45 Pro Midi Excavator Specs side
Volvo EC45 Pro Midi Excavator Specs side
Volvo EC45 Pro Midi Excavator Specs extended
Volvo EC45 Pro Midi Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

16.47 ft in

C

Shipping Height of Unit

8.34 ft in

I

Max Cutting Height

16.18 ft in

J

Max Loading Height

11.55 ft in

K

Max Reach Along Ground

17.66 ft in

L

Max Vertical Wall Digging Depth

6.53 ft in

M

Max Digging Depth

11.88 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

16.47 ft in

C

Shipping Height of Unit

8.34 ft in

I

Max Cutting Height

16.67 ft in

J

Max Loading Height

12.05 ft in

K

Max Reach Along Ground

18.61 ft in

L

Max Vertical Wall Digging Depth

7.45 ft in

M

Max Digging Depth

12.83 ft in

Dimensions

B

Width to Outside of Tracks

5.91 ft in

D

Length of Track on Ground

5.81 ft in

E

Ground Clearance

1.05 ft in

G

Height to Top of Cab

8.34 ft in

H

Tail Swing Radius

4.66 ft in

Undercarriage

N

Shoe Size

15.75 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2251

Engine Model

K4N

Gross Power

38 hp

Net Power

34 hp

Power Measured @

2600 rpm

Displacement

139.8 cu in

Max Torque

93 lb ft

Torque Measured @

1400 rpm

Aspiration

natural

Operational

Operating Weight

10031.1 lb

Fuel Capacity

17.5 gal

Cooling System Fluid Capacity

2.3 gal

Hydraulic System Fluid Capacity

9.8 gal

Engine Oil Capacity

2 gal

Operational Voltage

12 V

Alternator Supplied Amperage

40 amps

Hydraulic System Relief Valve Pressure

3771 psi

Hydraulic Pump Flow Capacity

26.2 gal/min

Swing Mechanism

Swing Speed

10 rpm

Undercarriage

Shoe Size

15.8 in

Number of Carrier Rollers per Side

1

Number of Track Rollers per Side

4

Ground Pressure

3.6 psi

Max Travel Speed

2.7 mph

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.3 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 2600mm / Stick 1400mm

Shipping Height of Unit

8.4 ft in

Shipping Length of Unit

16.5 ft in

Max Digging Depth

11.9 ft in

Max Reach Along Ground

17.7 ft in

Max Cutting Height

16.2 ft in

Max Loading Height

11.6 ft in

Max Vertical Wall Digging Depth

6.6 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 2600mm / Stick 1700mm

Shipping Height of Unit

8.4 ft in

Shipping Length of Unit

16.5 ft in

Max Digging Depth

12.9 ft in

Max Reach Along Ground

18.7 ft in

Max Cutting Height

16.7 ft in

Max Loading Height

12.1 ft in

Max Vertical Wall Digging Depth

7.5 ft in

Dimensions

Width to Outside of Tracks

6 ft in

Height to Top of Cab

8.4 ft in

Ground Clearance

1.1 ft in

Removal Counterweight Clearance

2.2 ft in

Tail Swing Radius

4.7 ft in

Length of Track on Ground

5.9 ft in
