Thomas 320 Multi Terrain Loader

Thomas 320 Multi Terrain Loader Specs front
Thomas 320 Multi Terrain Loader Specs front
Thomas 320 Multi Terrain Loader Specs back
Thomas 320 Multi Terrain Loader Specs back
Thomas 320 Multi Terrain Loader Specs extended
Thomas 320 Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

B

Width Over Tracks

6.52 ft in

C

Height to Top of Cab

7.01 ft in

E

Ground Clearance

9.02 in

G

Clearance at Max Lift and Dump

7.91 ft in

H

Reach at Max Lift and Dump

1.93 ft in


Specifications

Engine

Engine Make

2334

Engine Model

V3300T

Gross Power

87.4 hp

Net Power

83 hp

Power Measured @

2750 rpm

Peak Torque

205 lb ft

Displacement

203 cu in

Operational

Operating Weight

10500 lb

Fuel Capacity

28.8 gal

Hydraulic System Fluid Capacity

24 gal

Alternator Supplied Amperage

60 amps

Max Speed - low range

6.8 mph

Max Speed - high range

12.4 mph

Loader

Breakout Force

7000 lb

Operating Load

3200 lb

Tipping Angle

6400 degrees

Undercarriage

Ground Pressure

5.8 psi

Width of Track

18 in

Hydraulic

Pump Flow

21 gal/min

Relief Valve Pressure

3000 psi

Dimensions

Width Over Tracks

6.6 ft in

Length with Bucket

12.2 ft in

Length with out Bucket

9.8 ft in

Height to Top of Cab

7.1 ft in

Ground Clearance

9.1 in

Clearance at Max Lift and Dump

8 ft in

Reach at Max Lift and Dump

2 ft in

Turning Radius from Center - machine rear

35 in

Turning Radius from Center - inc bucket

44.9 in
