Caterpillar 279C Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
6.5ft in
C
Height To Top Of Cab
6.95ft in
E
Ground Clearance
9.1in
G
Clearance At Max Lift And Dump
7.97ft in
H
Reach At Max Lift And Dump
1.95ft in
Length - Track On Ground
69.6in
Length - With Bucket On Ground
144.81in
Length - Without Bucket
116.5in
Length With Out Bucket
9.72ft in
Bucket Pin Height - Maximum Lift
10.27ft in
Clearance At Maximum Lift And Dump
95.6in
Departure Angle
44 degrees
Height - Top Of Cab
6.95ft in
Turning Radius From Center - Inc Bucket
91.11in
Turning Radius From Center - Machine Rear
64.57in
Vehicle Width
78in
Length With Bucket
12.08ft in
Bucket Pin Height - Carry Position
7.7in
Maximum Dump Angle
40 degrees
Maximum Overall Height
157.7in
Maximum Reach - With Arms Parallel
54.6in
Overall Length - Track
89.4in
Rack Back Angle - Maximum Height
85 degrees
Reach At Maximum Lift/Dump
23.4in
Turn Radius From Center - Bucket
91.1in
Turn Radius From Center - Coupler
57.9in
Turn Radius From Center - Rear
64.6in
Undercarriage
D
Length Of Track On Ground
5.8ft in
Ground Contact Area
2504in2
Ground Pressure
4psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
C3.4 DIT
Gross Power
84hp
Net Power
82hp
Power Measured @
2500rpm
Displacement
201cu in
Bore
3.4in
Stroke
4.7in
Aspiration
Turbocharged
Gross Power - Sae J1995
84hp
Engine Model
Cat C3.4T
Net Power - Sae 1349
82hp
Operational
Operating Weight
9892lb
Cooling System Fluid Capacity
3.7gal
Engine Oil Capacity
2.7gal
Fuel Capacity
25.9gal
Hydraulic System Fluid Capacity
15.1gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Max Speed - Low Range
5.1mph
Max Speed - High Range
8.5mph
Power Train
Travel Speed Forward - 2-Speed
8.5mph
Travel Speed Reverse - 2-Speed
8.5mph
Travel Speed Forward
5mph
Travel Speed Reverse
5mph
Loader
Breakout Force
7308lb
Operating Load
3200lb
Tipping Angle
6483degrees
Bucket Capacity
0.6yd3
Weights
Operating Weight
9892lb
Hydraulic
Pump Flow
22.2gal/min
Relief Valve Pressure
3335psi
Hydraulic System
Hydraulic Flow (1)
Standard
Hydraulic Power
42.8hp
Maximum Loader Hydraulic Flow
33 gal/min
Maximum Loader Hydraulic Pressure
4061 psi
Loader Hydraulic Pressure
3335 psi
Loader Hydraulic Flow
22 gal/min
Hydraulic Flow (2)
High Flow XPS
Operating Specifications
Rated Operating Capacities - 50% Tipping Load
3200lb
Rated Operating Capacities - 35% Tipping Load
2240lb
Ground Contact Area
2504in2
Ground Pressure
4 psi
Rated Operating Capacity With Optional Counterweight
3465lb
Tipping Load
6483lb
Breakout Force - Tilt Cylinder
7308lb
Service Refill Capacities
Cooling System
3.7gal
Fuel Tank
26gal
Hydraulic Tank
11gal
Engine Crankcase
2.6gal
Hydraulic System
15gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J1043 SEPT87, ISO 3449:1992 Level I
Fops Level Ii
SAE J231 JAN81, ISO 3449:1992 Level II
