Terex TC29 Mini Excavator

Terex TC29 Mini Excavator Specs front
Terex TC29 Mini Excavator Specs front
Terex TC29 Mini Excavator Specs side
Terex TC29 Mini Excavator Specs side
Terex TC29 Mini Excavator Specs extended
Terex TC29 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

13.36 ft in

J

Max Loading Height

9.32 ft in

L

Max Vertical Wall Digging Depth

4.93 ft in

M

Max Digging Depth

9.06 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

13.75 ft in

J

Max Loading Height

9.72 ft in

L

Max Vertical Wall Digging Depth

5.09 ft in

M

Max Digging Depth

9.72 ft in

Dimensions

B

Width to Outside of Tracks

4.6 ft in

E

Ground Clearance

0.89 ft in

G

Height to Top of Cab

8.21 ft in

H

Tail Swing Radius

4.27 ft in

Undercarriage

F

Track Gauge

3.61 ft in

N

Shoe Size

11.82 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2251

Engine Model

S 4L

Net Power

28 hp

Power Measured @

2200 rpm

Displacement

91 cu in

Operational

Operating Weight

6480 lb

Fuel Capacity

13.8 gal

Hydraulic System Fluid Capacity

22.5 gal

Operating Voltage

12 V

Hydraulic System Relief Valve Pressure

3050 psi

Hydraulic Pump Flow Capacity

26.2 gal/min

Swing Mechanism

Swing Speed

10 rpm

Undercarriage

Shoe Size

11.9 in

Ground Pressure

3.9 psi

Max Travel Speed

2.9 mph

Drawbar Pull

6300 lb

Track Gauge

3.7 ft in

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.2 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

boom w/ dipperstick 53'' (1350mm)

Max Digging Depth

9.1 ft in

Max Cutting Height

13.4 ft in

Max Loading Height

9.4 ft in

Max Vertical Wall Digging Depth

5 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

boom w/ dipperstick 61'' (1550mm)

Max Digging Depth

9.8 ft in

Max Cutting Height

13.8 ft in

Max Loading Height

9.8 ft in

Max Vertical Wall Digging Depth

5.1 ft in

Dimensions

Width to Outside of Tracks

4.6 ft in

Height to Top of Cab

8.3 ft in

Ground Clearance

0.9 ft in

Tail Swing Radius

4.3 ft in
