Terex RH170B Shovel

Shovel
Shovel
Shovel
Shovel
Shovel
Shovel
Shovel
Shovel
Shovel
Shovel
Units

Dimensions

Dimensions

B

Width Over Tracks

21.66 ft in

D

Length of Track on Ground

20.35 ft in

E

Ground Clearance

3.22 in

G

Height to Top of Cab

25.83 ft in

Loading Shovel

I

Max Cutting Height

47.25 ft in

J

Max Dump Height

35.77 ft in

M

Max Dig Depth

8.54 ft in

Q

Max Cutting Height

47.25 ft in

R

Max Dump Height

35.77 ft in

S

Max Dig Reach

50.53 ft in

T

Max Dig Depth

8.54 ft in

Undercarriage

H

Tail Swing Radius

22.25 ft in

F

Track Gauge

17.72 ft in

N

Loading Shovel Shoe Width

47.25 in


Specifications

Engine

Number of Cylinders

12

Engine Make

2236

Engine Model

2x C32

Gross Power

2032 hp

Net Power

2032 hp

Power Measured @

1750 rpm

Displacement

1959 cu in

Aspiration

Turbocharged and air to air aftercooled

Operational

Fuel Capacity

2060.6 gal

Hydraulic System Fluid Capacity

792.6 gal

Swing Speed

4.7 rpm

Operating Voltage

24 V

Alternator Supplied Amperage

300 amps

Undercarriage

Max Travel Speed

1.7 mph

Number of Upper Rollers

2

Number of Lower Rollers

7

Number of Track Shoes per Side

42

Track Gauge

17.8 ft in

Loading Shovel Shoe Width

47.3 in

Loading Shovel Operating Weight

868180.4 lb

Loading Shovel Ground Pressure

34.1 psi

Tail Swing Radius

22.3 ft in

Loading Shovel

Loading Shovel

boom 23'11" (7300mm) w/ stick 15'1" (4600mm)

Max Dig Depth

8.6 ft in

Max Cutting Height

47.3 ft in

Max Dump Height

35.8 ft in

Max Dig Reach

50.6 ft in

Dimensions

Width Over Tracks

21.7 ft in

Height to Top of Cab

25.9 ft in

Length of Tracks

26.5 ft in

Length of Track on Ground

20.4 ft in

Ground Clearance

3.3 in

Upper Structure Ground Clearance

8.4 ft in

Height of Tracks

7.3 ft in
