Terex MT3700B Rock Truck

Terex MT3700B Rock Truck Specs front
Terex MT3700B Rock Truck Specs front
Terex MT3700B Rock Truck Specs side
Terex MT3700B Rock Truck Specs side
Terex MT3700B Rock Truck Specs back
Terex MT3700B Rock Truck Specs back
Units

Dimensions

Dimensions

A

Overall Length

42.98 ft in

B

Overall Width

23.96 ft in

C

Overall Height

22.64 ft in

D

Wheelbase

18.38 ft in

F

Dump Height

39.05 ft in

G

Dump Ground Clearance

5.25 ft in

Dump

H

Dump Angle

45 degrees


Specifications

Engine

Number of Cylinders

12

Engine Make

2350

Engine Model

12V 4000

Gross Power

1725 hp

Net Power

1575 hp

Operational

Fuel Capacity

760.1 gal

Cooling System Fluid Capacity

92 gal

Engine Oil Capacity

39.9 gal

Hydraulic System Fluid Capacity

220.1 gal

Operating Voltage

24 V

Alternator Supplied Amperage

100 amps

Tire Size

37.00R57

Transmission

Max Speed

34.2 mph

Weights

Empty Weight

287942 lb

Loaded Weight

667942 lb

Weight Distribution Front - empty

47.3 %

Weight Distribution Rear - empty

52.7 %

Weight Distribution Front - loaded

32.7 %

Weight Distribution Rear - loaded

67.3 %

Dump

Rated Payload

410000 lb

Load Capacity - Struck

100.8 yd3

Load Capacity - heaped

145.2 yd3

Dump Angle

45 degrees

Raise Time

19 sec

Lower Time

12 sec

Dimensions

Overall Length

43 ft in

Overall Width

24 ft in

Overall Height

22.7 ft in

Wheelbase

18.4 ft in

Dump Height

39.1 ft in

Dump Ground Clearance

5.3 ft in
