Hitachi EH3500ACII Rock Truck
Units
Dimensions
Dimensions
A
Overall Length
44.3ft in
B
Overall Width
26.28ft in
C
Overall Height
22.22ft in
Dump
Lower Time
13sec
Rated Payload
407855.16lb
Raise Time
17.5sec
Load Capacity - Heaped
145.19yd3
Load Capacity - Struck
96.79yd3
Specifications
Engine
Number Of Cylinders
16
Engine Make
2347
Engine Model
QSK50
Gross Power
2000hp
Net Power
1874hp
Power Measured @
1900rpm
Aspiration
Turbocharged
Displacement
3069.5cu in
Operational
Fuel Capacity
779.4gal
Cooling System Fluid Capacity
140.3gal
Engine Oil Capacity
52.9gal
Hydraulic System Fluid Capacity
208.5gal
Operating Voltage
24V
Tire Size
37.00R57 E4 Radials
Transmission
Max Speed
34.8mph
Weights
Empty Weight
308642lb
Loaded Weight
716490lb
Weight Distribution Front - Empty
48%
Weight Distribution Rear - Empty
52%
Weight Distribution Front - Loaded
31%
Weight Distribution Rear - Loaded
69%
