Terex HR2.0 Mini Excavator

Terex HR2.0 Mini Excavator Specs front
Terex HR2.0 Mini Excavator Specs front
Terex HR2.0 Mini Excavator Specs side
Terex HR2.0 Mini Excavator Specs side
Terex HR2.0 Mini Excavator Specs extended
Terex HR2.0 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

11.88 ft in

J

Max Loading Height

8.54 ft in

K

Max Reach Along Ground

13.78 ft in

L

Max Vertical Wall Digging Depth

3.15 ft in

M

Max Digging Depth

7.55 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

12.28 ft in

J

Max Loading Height

8.93 ft in

K

Max Reach Along Ground

14.34 ft in

L

Max Vertical Wall Digging Depth

3.71 ft in

M

Max Digging Depth

8.21 ft in

Dimensions

B

Width to Outside of Tracks

3.29 ft in

E

Ground Clearance

0.56 ft in

H

Tail Swing Radius

3.94 ft in

Undercarriage

N

Shoe Size

9.06 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2251

Engine Model

L3E-W 262 KL

Net Power

18 hp

Power Measured @

2400 rpm

Displacement

58 cu in

Max Torque

39.9 lb ft

Torque Measured @

1500 rpm

Operational

Operating Weight

4409.3 lb

Fuel Capacity

8 gal

Hydraulic System Fluid Capacity

9.3 gal

Operational Voltage

12 V

Hydraulic System Relief Valve Pressure

2610 psi

Hydraulic Pump Flow Capacity

15.4 gal/min

Swing Mechanism

Swing Speed

10 rpm

Undercarriage

Shoe Size

9.1 in

Max Travel Speed

2.6 mph

Drawbar Pull

3375 lb

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.1 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Monobloc boom Dipperstick 1100mm

Max Digging Depth

7.6 ft in

Max Reach Along Ground

13.8 ft in

Max Cutting Height

11.9 ft in

Max Loading Height

8.6 ft in

Max Vertical Wall Digging Depth

3.2 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Monobloc boom Dipperstick 1300mm

Max Digging Depth

8.3 ft in

Max Reach Along Ground

14.4 ft in

Max Cutting Height

12.3 ft in

Max Loading Height

9 ft in

Max Vertical Wall Digging Depth

3.8 ft in

Dimensions

Width to Outside of Tracks

3.3 ft in

Ground Clearance

0.6 ft in

Tail Swing Radius

4 ft in
