Volvo EC20BXTV Mini Excavator

Volvo EC20BXTV Mini Excavator Specs front
Volvo EC20BXTV Mini Excavator Specs front
Volvo EC20BXTV Mini Excavator Specs side
Volvo EC20BXTV Mini Excavator Specs side
Volvo EC20BXTV Mini Excavator Specs extended
Volvo EC20BXTV Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

12.41 ft in

C

Shipping Height of Unit

7.45 ft in

I

Max Cutting Height

12.31 ft in

J

Max Loading Height

8.76 ft in

K

Max Reach Along Ground

13.16 ft in

L

Max Vertical Wall Digging Depth

5.19 ft in

M

Max Digging Depth

7.71 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

12.41 ft in

C

Shipping Height of Unit

7.45 ft in

I

Max Cutting Height

12.8 ft in

J

Max Loading Height

9.26 ft in

K

Max Reach Along Ground

13.95 ft in

L

Max Vertical Wall Digging Depth

5.91 ft in

M

Max Digging Depth

8.54 ft in

Dimensions

B

Width to Outside of Tracks

4.43 ft in

D

Length of Track on Ground

4.07 ft in

G

Height to Top of Cab

7.45 ft in

H

Tail Swing Radius

3.81 ft in

Undercarriage

F

Track Gauge

3.29 ft in

N

Shoe Size

10 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2251

Engine Model

L3E

Net Power

15.2 hp

Power Measured @

2200 rpm

Displacement

58 cu in

Max Torque

40 lb ft

Torque Measured @

1850 rpm

Aspiration

Natural

Operational

Operating Weight

4134 lb

Fuel Capacity

5.6 gal

Cooling System Fluid Capacity

1.2 gal

Hydraulic System Fluid Capacity

6.1 gal

Engine Oil Capacity

1 gal

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Hydraulic System Relief Valve Pressure

3045 psi

Hydraulic Pump Flow Capacity

11.4 gal/min

Swing Mechanism

Swing Speed

10 rpm

Undercarriage

Shoe Size

10 in

Ground Pressure

4 psi

Max Travel Speed

2.9 mph

Track Gauge

3.3 ft in

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.2 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 6'3" (1900mm)/Stick 3'5" (1050mm)

Shipping Height of Unit

7.5 ft in

Shipping Length of Unit

12.5 ft in

Max Digging Depth

7.8 ft in

Max Reach Along Ground

13.2 ft in

Max Cutting Height

12.4 ft in

Max Loading Height

8.8 ft in

Max Vertical Wall Digging Depth

5.2 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 6'3" (1900mm)/Stick 4'3" (1300mm)

Shipping Height of Unit

7.5 ft in

Shipping Length of Unit

12.5 ft in

Max Digging Depth

8.6 ft in

Max Reach Along Ground

14 ft in

Max Cutting Height

12.8 ft in

Max Loading Height

9.3 ft in

Max Vertical Wall Digging Depth

6 ft in

Dimensions

Width to Outside of Tracks

4.5 ft in

Height to Top of Cab

7.5 ft in

Removal Counterweight Clearance

1.6 ft in

Tail Swing Radius

3.9 ft in

Length of Track on Ground

4.1 ft in
